Core Dual Xeon® LaserBlade 8U Singlewide LB8-X1-XX LaserBlade Specifications



	Core 2 Duo Blade Specs 4U singlewide 8U singlewide onboard graphics 8U singlewide 3rd party graphics Core 2 Quad Blade Specs 4U singlewide 8U singlewide onboard graphics 8U singlewide 3rd party graphics Dual Core Xeon Blade Specs 4U singlewide 8U singlewide 8U doublewide Quad Core Xeon Blade Specs 4U singlewide 8U singlewide 8U doublewide Management CubixView CubixVision Management Console

Key Features	PCI-X and PCI adapter support Dual processor option Hot plug drive support ECC DRAM Two on-board Ethernet ports
Form factor	13.10”H x 2.1"W x 20.67”D
Processor(s)	1 or 2 dual-core / quad core Intel Xeon processors 5000/5100/5300
Memory	6 slots maximum 24GB Dual channel DDR2 533/667 Fully-buffered DIMMs sizes 512MB, 1 GB, 2 GB, 4GB
Chipset	Intel® 5000V chipset
Video	ATI® ES1000
I/O Connections	1 external serial port 2 external USB port 1 VGA port 2 RJ-45 1 PS/2 keyboard / mouse
USB 2.0	4 ports
LAN	Intel® 82563EB dual-port
Drives	SATA on board controller SAS optional controller? 2 drives per blade Hot Plug support optional
Management	CubixVision
Expansion	PCI-X 133/100 MHz PCI 32 bit/33 MHz
